Flame-Power 4/4 can manage of any type and any fuel type 2-stroke, 4-stroke, wankel engines with spark ignition with volume 20... 6400 cm3.
Flame-Power 4/4 simultaneously controls fuel injection and spark ignition.
Device can be used immediately after simplified “smart” setup process or preciously tuned by professionals.
Product features
Aluminum case with IP65 protection permit to use our EMS for motorcycles, outboards, snowmobiles, aircrafts, paramotors and UAVs.
4 independent channels for ignitions and 4 channels for fuel injections allow use device for any 1, 2, 3 or 4-cylinder engine configuration (inline, opposite, V) and for some 6 or 8-cylinder configurations (inline, opposite, V90).
Initial fuel maps generated by 2 main algorithms:
Table fuel amount vs throttle angle (Alpha-N)
Calculation air speed in throttle body (Speed Density)
For further very detailed EMS setup it is possible to use our proprietary software or free EFI Analytics TunerStudio.
Flame-Power 4/4 functions:
Management of 2-stroke, 4-stroke and rotor( wankel) engines
Management of 2 rows of independent fuel nozzles
Precise nozzle open close phases vs crankshaft angle
Linear lambda regulation on all rpm range
4 independent ignition channels
4 independent injection channels
Fuel pump management
Easy initial fuel maps generation using only few engine parameters
Onboard telemetry and possibility write intense engine logs on external computer or Smartphone.
